Fusion is the world’s most advanced compositing software for visual effects artists, broadcast and motion graphic designers and 3D animators. It has been used on over 1000 major Hollywood blockbuster feature films. Fusion features an easy and powerful node based interface so you can construct complex effects simply by connecting various types of processing together.

Component Recommendations

Processor Processor

Compositing

Video compositing relies on both a high amount of CPU cores and high clockspeed. Therefore we recommend a 6- to 12-core processor over 3.0GHz.

Note: Flame is only compatible with Linux, not Windows. CentOS Linux is recommended for your configuration.

Memory Memory

In general, 3-6GB of RAM per CPU core is recommended. For example, if you select a single 12-core processor, 32GB will suffice for basic tasks or 64GB for more demanding workloads.

With video editing, the amount of RAM required generally depends on the resolution of the video and the complexity of your timeline. As a general rule of thumb we recommend 24GB/32GB/48GB if you work with 1080p footage, 48GB/64GB/96GB for 4K footage, 96GB/128GB/196GB for 6K footage, and 196GB/256/384GB if you work with 8K footage.

Storage Storage

We recommend having two drives which provides the best performance:

  1. Primary Drive: SSD for the operating system and software
  2. Secondary Drive: another SSD, or for better performance, an NVMe Flash Storage Drive (the "HP Z Turbo Drive") for active project files

If you need additional storage for large, infrequently accessed files, we also recommend one or more 4TB, 6TB or 8TB+ hard drives. Hard drives also work well for storing export files as the export/rendering process is generally not write intensive.

The Z Turbo Drive Quad Pro yields the absolute maximum in performance - remarkable drive speeds combined with massive flash storage capacity. Supporting up to four m.2 NVMe flash storage drives on one PCIe slot, each reaching 1750MB/s write and 2500MB/s read speeds, the Z Turbo Drive Quad Pro is the ultimate footage drive. We recommend the Quad Pro in these two configurations:

  1. One drive in the Quad Pro as primary - dedicated for the operating system and applications. Three drives in RAID configuration as a editing/footage partition - dedicated for storage of the project, source media, media cache and scratch files. A 3-drive RAID 0 configuration in the Quad Pro achieves speeds of 6GB/s, which is perfect for a 6K or 8K workflow. The benefit of this route is conserving a PCIe slot - the primary and editing partitions both on one PCIe slot opening a secondary PCIe slot for a specialty or port-expansion card.
  2. All four drives in the Quad Pro in RAID 0 configuration dedicated as the editing/footage partition. Drive speeds reaching 9GB/s and up to 8TB capacity. Select a separate SATA 3 solid-state drive (SSD) or m.2 NVMe drive (HP Z Turbo Drive) for the operating system and appications. The benefit of this route is unparalled performance.

RAID 0 configurations are optimized for performance. Also known as disk striping, RAID 0 spreads the data across multiple phyical drives, allowing multiple disks to access the contents of a file, thus writes and reads will be completed quicker. The drawback to RAID 0 is that if a drive should fail, all data would be lost. Thus, we recommend back up of data on a RAID 0 using a standard spindle 7,200rpm hard drive.

Graphics Graphics

For post production video editing, we recommend NVIDIA GeForce RTX graphics cards as they provide high performance at a great value compared to Quadro cards.

For lower budget systems, we recommend a single NVIDIA GeForce RTX 2080.

For higher budget systems, we recommend a single NVIDIA GeForce RTX 2080Ti.

If your application scales well with multiple graphics cards we recommend two RTX 2080Ti . If your application takes advantage of only one graphics card or does not scale well, we recommend going with the single RTX Titan 24GB.

Read More: GeForce GTX vs. Quadro Graphics Cards

Chassis Chassis

The HP Z8 G4 Workstation is recommended if you would like dual processors and/or multiple high performance graphics cards.

The HP Z6 G4 Workstation is recommended if you would like to start with a single high-end processor and single high-performance graphics card with the potential of upgrading in the future. With the Z6 G4, you can add a second matching processor and double the memory using the optional second processor riser. The power supply will also support two mid-range graphics cards.

The HP Z4 G4 Workstation is recommended for majority of workflows. Since Intel now produces single Core i9 and Xeon processors with up to 18-cores and high clock speed, there is no need for dual processors unless you will have heavy CPU rendering or intensive tasks demanding more than 18-cores. Also, the HP Z4 G4 has an optional 1000W power supply that will support the most powerful graphics cards inluding the GeForce RTX 2080Ti and Quadro RTX 6000.

Configuration Recommendations

HP Z8 G4 Workstation

  • Dual 8 cores, 3.5 GHz base frequency | Intel Xeon Gold 6144
  • 96GB (6x 16GB) of 2666MHz DDR4 ECC Registered Memory
  • 2TB NVMe M.2 Solid-State Drive
  • 1TB NVMe M.2 Solid-State Drive
  • NVIDIA GeForce RTX 2080Ti 11GB
  • NVIDIA GeForce RTX 2080Ti 11GB

$14,550

Customize & Buy

HP Z8 G4 Workstation

  • 18 cores, 3.0 GHz base frequency | Intel Xeon Gold 6154
  • 64GB (4x 16GB) of 2666MHz DDR4 ECC Registered Memory
  • 512GB NVMe M.2 Solid-State Drive
  • 1TB NVMe M.2 Solid-State Drive
  • NVIDIA GeForce RTX Titan 24GB

$10,050

Customize & Buy

HP Z840 Workstation

  • 12-Core 3.0GHz Intel Xeon Broadwell E5-2687W v4 [12-cores / 24-threads]
  • 64GB (4x 16GB) of 2400MHz DDR4 ECC Registered RAM
  • 1TB NVMe M.2 Solid-State Drive
  • NVIDIA GeForce GTX 1080Ti 11GB

$6,150

Customize & Buy

HP Z4 G4 Workstation

  • Intel Core i9-9980XE (3.0 GHz base frequency, 18 cores)
  • 64GB (4x 16GB) of 2666MHz DDR4 Memory
  • 1TB NVMe M.2 Solid-State Drive
  • NVIDIA GeForce RTX 2080Ti 11GB

$6,600

Customize & Buy

HP Z4 G4 Workstation

  • Intel Core i9-9900X (3.5 GHz base frequency, 10 cores)
  • 32GB (4x 8GB) of 2666MHz DDR4 Memory
  • 1TB NVMe M.2 Solid-State Drive
  • NVIDIA GeForce RTX 2080 8GB

$4,500

Customize & Buy

HP Z440 Workstation

  • Quad-Core 3.7GHz Intel Xeon Broadwell E5-1630 v4 [4-cores / 8-threads]
  • 32GB (4x 8GB) of 2400MHz DDR4 ECC Registered RAM
  • 1TB SATA3 2.5" Solid-State Drive
  • NVIDIA GeForce GTX 1080 8GB

$2,750

Customize & Buy
